Procedural optical fibres

Overview: A collection of Geometry Node (GN) modifiers to create procedural optical fibres. Included in this pack are:
1) Conventional single-mode/multi-mode fibre, 2) Hollow core photonic crystal fibre (PCF), 3) Hollow antiresonant fibre, 4) Hollow core Bragg fibre.

Controls are available to fully customise each fibre. This includes common fibre parameters (core/cladding radii, coating thickness, ability to strip layers) and fibre-specific parameters (eg air hole pitch, radius in PCF).

Documentation of the parameters can be found in the image panel above (2nd image).

Please note: this collection is intended to help create simplified schematics that involve optical fibres.

Compatibility: For Blender 3.6.0 onwards.

Attribution: Please provide attribution to Ryo Mizuta Graphics wherever this asset is used for commercial/published academic work (e.g. publication figures, presentations, etc). Please consider tagging any posts on Twitter (@Ryo_M_Graphics) and Instagram (@ryomizuta_graphics) whenever this asset is used/publicized on social media.
